Constant Voltage Power Supply Mean Well PWM-120-24BLE IP67 230V to 24V 5A 120W with Casambi Dimming

With the Meanwell PWM-120-24BLE, the connected modules, strips or luminaires can be conveniently controlled and dimmend via smartphone or tablet. This is made possible by the built-in Casambi module, which transmits the signals from the app directly to the connected light source via Bluetooth. The Casambi app is available free of charge for both iOS- and Android-based devices.

Casambi enables indoor and commercial luminaires to be controlled via Bluetooth Low Energy 4.0 mesh protocol. Casambi's Bluetooth mesh network solution integrated into the series automatically connects to wireless mesh networks, allowing control of numerous luminaires from a single point without additional gateways. The Casambi Bluetooth app even connects to the cloud for data storage, and many Bluetooth control devices are available for instant use.

Before starting, all that is required is to download the app to a smartphone or tablet for setting up scenes, timers, etc. To expand the network and develop personalized intelligent lighting control systems, it is also possible to connect PWM-120-24BLE to all Casambi-compatible devices such as wall switches or light sensors.

The constant voltage source operates with 90-305 VAC input voltage and provides 24 V at the output. Thanks to its high efficiency of up to 90% and fanless design, the PWM-120-24BLE can operate at -20°C to +90°C case temperature under free air convection. The constant voltage driver has IP67 protection and is suitable for use in dry, damp or wet rooms.

Features of the Meanwell PWM-120-24BLE Casambi enabled transformer

• With integrated CASAMBI module
• Can be controlled via CASAMBI app using smartphone, tablet and CASAMBI-capable switch (e.g. CASAMBI Xpress) for dimming or on/off of LED modules and strips
• Input voltage range: 90 - 305 VAC
• Output voltage: 24 V
• Output power: 120 W
• Recommended for all LumiFlex LED strips, including LumiFlex3098+, LumiFlex3095, LumiFlex3090, LumiFlex2080
• Efficiency: up to 90%
• Protected against overheating, overvoltage, overload and short circuit
• Protection class II
• Complies with the following standards, among others: EN61547, EN61000-3-2, 3, EN61547, EN55015, EN61000-4-2, 3, 4, 5, 6, 8, 11
• For LED and lighting applications
• Built-in PFC circuit, auto recovery
• Operating temperature: -20° C - +90° C
• Protection class: IP67
• Dimensions (L x W x H): 191 x 63 x 37.5 mm
• Weight: 970 g
